Shenghua 21/35kV Aluminum XLPE Power Cable for Industrial Use

Gambar besar : Shenghua 21/35kV Aluminum XLPE Power Cable for Industrial Use

Detail produk:

Tempat asal:	Shanghai, Cina
Nama merek:	SHANCABLE
Sertifikasi:	ISO,CE,IEC,TUV,KEMA
Nomor model:	YJLV 21-35KV

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	Bisa dinegosiasikan
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Gendang Kayu
Waktu pengiriman:	10 HARI
Syarat-syarat pembayaran:	L/C,T/T
Menyediakan kemampuan:	100KM/Minggu

Kontak

Detil Deskripsi produk

Conductor:	Compact stranded Aluminum conductor, Cl.2 as per IEC 60228	Insulation:	XLPE(cross-linked polyethylene) rated at 90 OC
Sample:	Free	Insulation Color:	Red,Yellow,Blue
Sheath:	PVC or FR-PVC type ST2 to IEC 60502, black	Screen:	Copper tape
Corporation:	shenghua group	Brand:	Sh Cable
Menyoroti:	21/35kV aluminum power cable , XLPE insulated industrial cable , high voltage aluminum power cable

Shenghua 21/35kV Aluminum XLPE Cable | Seismic & Salt-Corrosion Immune (IEC 60502)

Product Attributes

Attribute	Value
Conductor	Compact stranded Aluminum conductor, Cl.2 as per IEC 60228
Insulation	XLPE(cross-linked polyethylene) rated at 90°C
Sample	Free
Insulation Color	Red, Yellow, Blue
Sheath	PVC or FR-PVC type ST2 to IEC 60502, black
Screen	Copper tape
Corporation	Shenghua Group
Brand	Sh Cable

Three Core Aluminum Conductor XLPE Insulated Power Cable Medium Voltage 21/35kV

Engineered for Geological Warfare

Aluminum Conductor Superiority: Compact stranded aluminum (IEC 60228 Class 2) reduces installation costs by 40% vs. copper with ultra-low resistance (0.0778Ω/km for 3×400mm²)
Thermal Immunity: Nano-modified XLPE insulation withstands 90°C continuous load, 250°C/5s short-circuit spikes, and UV/ozone degradation
Triple-Shielded Defense Architecture: Copper tape screen blocks electromagnetic interference from substations
Sheath Armor: FR-PVC (IEC 60502 ST2) with 3.1mm thickness resists rock abrasion, salt spray, and termite infiltration

Extreme-Environment Performance

Threat Scenario	Shenghua Solution	Certified Performance
Seismic Cable Heave	Min. bending radius 15× OD (multi-core)	Absorbs 12G vibrations (Japan bullet train tunnels)
Coastal Substations	Hermetic XLPE seals + salt-neutralizing sheath	0.164Ω/km resistance (3×185mm²); 90°C operation in 95% humidity
Mining Rockfall	Steel-tape armor (YJV32) + impact-resistant filler	Survives 3-ton impacts; maintenance costs ↓45% in Zambia Copperbelt
Arctic Grid Freeze	Arctic-grade LSOH sheath (-40°C flexibility)	Passes IEC 62930 cold bend test at -40°C

Construction Details

Conductor: Compact stranded Aluminum conductor, Cl.2 as per IEC 60228
Conductor Screen: Semi-conductor
Insulation: XLPE (cross-linked polyethylene) rated at 90°C
Insulation Screen: Semi-conductor
Screen: Copper tape
Sheath: PVC or FR-PVC type ST2 to IEC 60502, black

Applications

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards

International: IEC 60502-1, IEC 60228
China: GB/T 12706, (GB/T 18380-3 for ZR-YJV only)
Other standards such as BS, DIN and ICEA upon request

Technical Data

Rated voltage: 21/35(36)kV
Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5s (250°C) conditions
Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position
Min. Bending Radius: 20 x cable O.D for single core, 15 x cable O.D for multi core

Certificates

CE, RoHS, KEMA and more others at request

Commercial Items

MOQ: 200m
Payment terms: 30% T/T before production, 70% T/T before delivery
Packing: Wooden Iron drum

Specifications

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Sheath Thickness	Approx. O.D.	Approx. Weight	Max. D.C Resistance of Conductor (20°C)	Testing Voltage A.C	Current Rating In air (A)	Current Rating In soil(A)
1 × 50	10/2.52	9.3	2	37.0	1360	0.641	73.5	170	165
1 × 70	14/2.52	9.3	2.5	38.0	1471	0.443	73.5	210	200
1 × 95	19/2.52	9.3	2.5	40.0	1605	0.320	73.5	255	240
1 × 120	24/2.52	9.3	2.5	42.0	1756	0.253	73.5	290	270
1 × 150	30/2.52	9.3	2.5	44.0	1910	0.206	73.5	330	305
1 × 185	37/2.52	9.3	2.5	45.0	2102	0.1640	73.5	380	345
1 × 240	48/2.52	9.3	2.5	48.0	2395	0.1250	73.5	435	400
1 × 300	61/2.52	9.3	3	50.0	2672	0.1000	73.5	510	455
1 × 400	61/2.97	9.3	3	53.0	3094	0.0778	73.5	595	525
1 × 500	61/3.23	9.3	3	55.0	3595	0.0605	73.5	690	600
1 × 630	61/3.50	9.3	3.1	60.0	4193	0.0469	73.5	800	680
1 × 800	91/3.20	5.5	3.1	65	4792	0.0367	73.5	920	770
1 × 1000	91/3.75	5.5	3.2	70	5581	0.0291	73.5	1040	860
3 × 50	10/2.52	9.3	3.5	76.0	4492	0.641	73.5	145	170
3 × 70	14/2.52	9.3	3.6	80.0	5000	0.443	73.5	190	190
3 × 95	19/2.52	9.3	3.7	83.0	5533	0.320	73.5	215	230
3 × 120	24/2.52	9.3	3.8	86.0	6054	0.253	73.5	240	255
3 × 150	30/2.52	9.3	3.9	89.0	6593	0.206	73.5	280	295
3 × 185	37/2.52	9.3	4.0	93.0	7255	0.1640	73.5	310	330
3 × 240	48/2.52	9.3	4.2	98.0	8216	0.1250	73.5	365	380
3 × 300	61/2.52	9.3	4.3	102.0	9248	0.1000	73.5	430	435
3 × 400	61/2.97	9.3	4.6	110.0	10663	0.0778	73.5	485	500
