Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Nama Produk: | Kabel Berinsulasi XLPE Bebas Halogen Asap Rendah | Aplikasi: | Terowongan Metro, Stasiun dan Bangunan Umum |
|---|---|---|---|
| Bahan Konduktor: | Tembaga Anil Terdampar Kelas 2, IEC 60228 | Tegangan terukur: | 0,6/1 kV (Um 1,2 kV) |
| Bagian Inti dan Penampang: | 5x16mm2 | Bahan Isolasi: | XLPE, Tebal Nominal 0,7 mm |
| Bahan Sarung: | Poliolefin Termoplastik LSZH, Bebas Halogen | Kepadatan Asap: | Transmisi Cahaya Di Atas 60 Persen sesuai IEC 61034 |
| Emisi Gas Asam: | Di bawah 5 mg/g menurut IEC 60754-2 | Standar Desain: | IEC 60502-1, IEC 60332-1 |
| Menyoroti: | 5x16mm2 Copper XLPE Insulated Cable,Low Smoke XLPE Insulated Cable,Halogen Free XLPE Insulated Cable |
||
Product Overview Five core 16mm2 distribution cable for tunnels, stations, hospitals and other enclosed spaces where a fire must not turn the escape route into a smoke-filled shaft. The LSZH oversheath contains no halogen and no PVC, so combustion produces very little hydrogen chloride gas and light transmittance stays above the sixty percent threshold in the IEC 61034 test. Copper conductors keep the resistance low, while the XLPE insulation tolerates a 90 C conductor
