Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Nama Produk: | Layar Pita Tembaga Tegangan Menengah Kabel Berisolasi XLPE | Aplikasi: | Substation 12/20kV dan Distribusi Utama Ring |
|---|---|---|---|
| Bahan Konduktor: | Tembaga Untai Dipadatkan Kelas 2, IEC 60228 | Tegangan terukur: | 12/20 kV (Um 24 kV) |
| Bagian Inti dan Penampang: | 3x120mm2 | SISTEM INSULASI: | XLPE, Tingkat Isolasi 133 Persen |
| Layar: | Lapisan Semi Konduktif yang Diekstrusi ditambah Layar Pita Tembaga | Jenis Armor: | Armor Pita Baja di bawah Selubung Luar |
| Selubung luar: | PVC Hitam, Dilapisi Grafit untuk Kontak Bumi | Standar Desain: | IEC 60502-2 |
| Menyoroti: | 3x120mm2 XLPE Insulated Cable,12/20kV CXLPE Insulated Cable,Copper Tape Screen XLPE Insulated Cable |
||
Product Overview Medium voltage feeders punish weak insulation design. This 12/20kV three core cable uses a triple extrusion process, where the semi conductive conductor screen, the XLPE insulation and the semi conductive insulation screen are applied in one pass inside a dry nitrogen curing tube. No dust, no moisture and no interface voids, which is exactly what partial discharge testing looks for at commissioning. The 133 percent insulation level gives this cable a thicker
